Compression Latch T-Handle Lock MS816-1E-2

1:1 Southco E3-11-15 Compression latches provide mechanical advantage, ensuring tight, robust vibration resistant door closure to seal out water and dust in the most strenuous applications. The smooth operation of the VISE ACTION® design aligns the cam behind the frame, then draws it straight up tight to prevent scraping against the frame, with a single continuous half-turn motion. Its compression action provides consistent 6.4 mm (.25”) pull-up for environmental sealing in gasketed applications, and helps reduce or eliminate noise and rattles caused by vibration. Over-center latching resists accidental opening due to shock or vibration.
get a quote

Compression Latch, Large Size, T-Handle, Zinc Alloy, Powder Coated MS816-1E-2

Item No MS816-1E-2    MS816-1E-2D
Ingress Protection (IP) Rating IP 65
Material Zinc Alloy
Finish Powder Coat
Color/Appearance Black
Access Restriction No Restriction
Grip Type Adjustable
Mounting Style Single Hole Mount
Head Style T-Handle
Series Standard
Min. Outer Panel Thickness (mm) 0.00
Max Outer Panel Thickness (mm) 18.00
Grip – Minimum (mm) 11.40
Grip – Maximum (mm) 27.20
Grip – Minimum (Cam Reversed) (mm) 66.30
Grip – Maximum (Cam Reversed) (mm) 76.20
Cam Attached Yes
Rotation Type A – Turn Clockwise to Latch
Application
  • Industrial machinery enclosures.
  • Telecommunication cabinets.
  • Medical equipment access panels.
  • Automotive control units.
Class Compression Latch
Size 19.1mm

Compression Latch
